Without or with Liquid Filling

Without or with Liquid Filling

Taxes included. Shipping calculated at checkout.

SKU :

press7

Calibration needed?
Without or with Liquid Filling
View full details
  • Description

Design
EN 837-3

Nominal size in mm
63, 100, 160

Accuracy class
1.6

Scale ranges
NS 63: 0 ... 40 mbar to 0 ... 600 mbar
NS 100: 0 ... 16 mbar to 0 ... 600 mbar
NS 160: 0 ... 2.5 mbar to 0 ... 600 mbar
or all other equivalent vacuum or combined pressure and vacuum ranges

Pressure limitation
Steady: full scale value
Fluctuating: 0.9 x full scale value

Operating temperature
Ambient: -20 ... +60 °C
Medium: +100 °C maximum

Temperature effect
When the temperature of the measuring system deviates from the reference temperature (+20 °C):
max. ±0.6 %/10 K of full scale value

Ingress protection
IP 54 per EN 60 529 / IEC 529
(with liquid filling IP 65)
