SPAN RESISTORSTemperature Compensation for Strain Gage Bridges

The Span Resistor / Temperature Compensation unit is designed to improve accuracy in strain-gage bridge circuits by offsetting temperature-induced drift. It ensures stability of measurements across changing thermal conditions, helping maintain reliable output over time. Ideal for applications where precise load or pressure measurement via strain gages is required under varying ambient or process temperatures.

Key Features:

Helps compensate for temperature drift in strain gage circuits

Provides stable span correction for more accurate readings

Compact design compatible with many bridge amplifier or transmitter setups

High reliability under fluctuating thermal conditions

Enables finer calibration of measurement systems

Applications:

Weight & load cell systems exposed to varying temperatures

Pressure transducers using strain-gage technology

Industrial measurement systems sensitive to thermal drift

Calibration laboratories needing stable, repeatable results
