Smart-Micro IR T/C Adding Smart Linearization to the Smallest IR

$1,264.59
Excl GST: $1,149.63
Sale Sold out
Taxes included. Shipping calculated at checkout.

SKU :

OS35RS

Calibration needed?
Smart-Micro IR T/C Adding Smart Linearization to the Smallest IR
View full details
  • Description
  • Download Brochures
The OS35RS Series is discontinued from 05/15/2018. Consider OS550A Sereis as a possible alternative or contact our Temperature Engineering department.
The smallest sized IR temperature sensor in the world now has brains. By combining the OS36-SM sensor head with the OS35 platform, precision in small places is now a reality. The OS35 processes the signal from the microIRt/c, linearizes, and gives an analog output (4 to 20 mA, 0 to 5V, 0 to 10V). Accuracy holds with changes in ambient from -45 to 100 °C, with no drifting. Four sensor heads with 1:2 and 4:1 optics, straight and side view mounting, built in air purge (cool to 120 °C), air purge jackets (cool to 175 °C), and mounting brackets are available.

Temperature Range Table (Table 1)
Temperature Code Temperature Range
100ºC 0 to 100ºC
250ºC 0 to 250ºC
70ºC -30 to 70ºC
500ºC (*) 0 to 500ºC
(*) This temperature range is only available with models of 4:1 FOV.

Output Options Table (Table 2)
Output Suffix Output Type
MA 4 to 20 mA
V10 (**) 0 to 10V
V5 0 to 5V
RS2 RS232 communications port
(**) This output range is only available with 24V power supply.

Power Supply Table (Table 3)
Power Supply Suffix Power
12V 12 Vdc power supply
24V 24 Vdc power supply
