Differential pressure (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product36

Calibration needed?
Design Per EN 837-3 and ventilation and air-conditioning (VAC) regulations Nominal size in mm 110 Accuracy class ±3 % (±5 % with scale range ≤ 0 ... 125 Pa) Scale ranges 0 … 50 Pa to 0 … 12,500 Pa -25 … +25 Pa to -1,500 … +1,500 Pa further plus/minus ranges on request Pressure limitation Steady: Full scale value Fluctuating: Full scale value Overpressure safety 20 kPa Max. working pressure (static pressure) 20 kPa Permissible temperature Ambient: -30 ... +80 °C Medium: -16 … +50 °C Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.5 %/10 K of full scale value Ingress protection IP 54 per EN 60529 / lEC 529
View full details
  • Description
  • Download Brochures

The Differential Pressure Gauge is a precision instrument designed to measure the difference in pressure between two points in a system. With a stainless steel construction, it offers durability and resistance to corrosion, making it suitable for harsh industrial environments. This gauge is ideal for applications such as HVAC systems, filtration processes, and fluid dynamics monitoring. For pricing and availability, please contact us directly.

Key Features:

Precision Measurement: Accurately measures differential pressure between two points.

Stainless Steel Construction: Offers durability and resistance to corrosion.

Wide Application: Suitable for HVAC systems, filtration processes, and fluid dynamics monitoring.

Easy Integration: Designed for straightforward installation into existing systems.

Customizable Options: Available in various pressure ranges and configurations.
