Differential Pressure (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product33

Calibration needed?
Design Small, compact version WIKA trade pattern DT-GM 87 10 226 Nominal size in mm 80 Accuracy class 4.0: scale ranges 0 ... 16 mbar and 0 ... 25 mbar 2.5: scale ranges 0 ... 40 mbar to 0 ... 600 mbar Scale ranges 0 ... 16 mbar to 0 ... 600 mbar or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: full scale value Fluctuating: full scale value Overpressure safety Either side max. 16 bar Max. working pressure (static pressure) 16 bar Operating temperature Ambient: -15 ... +60 °C Medium: +70 °C maximum Temperature effect When temperature of the measuring system deviates from reference temperature (+20 °C): max. ±0.5 %/10 K of true scale value Ingress protection lP 66 per EN 60 529 / lEC 529
View full details
  • Description
  • Download Brochures
Design Small, compact version WIKA trade pattern DT-GM 87 10 226 Nominal size in mm 80 Accuracy class 4.0: scale ranges 0 ... 16 mbar and 0 ... 25 mbar 2.5: scale ranges 0 ... 40 mbar to 0 ... 600 mbar Scale ranges 0 ... 16 mbar to 0 ... 600 mbar or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: full scale value Fluctuating: full scale value Overpressure safety Either side max. 16 bar Max. working pressure (static pressure) 16 bar Operating temperature Ambient: -15 ... +60 °C Medium: +70 °C maximum Temperature effect When temperature of the measuring system deviates from reference temperature (+20 °C): max. ±0.5 %/10 K of true scale value Ingress protection lP 66 per EN 60 529 / lEC 529
