Differential pressure gauge with capsule (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product32

Calibration needed?
Design For very low differential pressures, DT - GM 87 10 226 Nominal size in mm Model 716.11: NS 63, 100, 160 Model 736.11: NS 100, 160 Accuracy class 1.6 Scale ranges Model 716.11: NS 63: 0 ... 16 to 0 ... 400 mbar NS 100: 0 ... 10 to 0 ... 250 mbar NS 160: 0 ... 6 to 0 ... 250 mbar Model 736.11: NS 100: 0 ... 16 to 0 ... 250 mbar NS 160: 0 ... 1.6 to 0 ... 250 mbar or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: Full scale value Fluctuating: 0.9 x full scale value Overpressure safety Full scale value Max. working pressure (static pressure) NS 63: 400 mbar NS 100, 160: 250 mbar Permissible temperature Ambient: -20 ... +60 °C Medium: +70 °C maximum Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.5 %/10 K of full scale value Ingress protection IP 66 per EN 60529 / lEC 529
View full details
  • Description
  • Download Brochures

The Differential Pressure Gauge with Capsule is a precision-engineered instrument designed for accurate measurement of very low differential pressures in air or non-corrosive gases. Built with a durable capsule element mechanism, it ensures superior sensitivity and repeatability, making it ideal for applications such as clean room monitoring, HVAC system balancing, filter condition checks, and laboratory process control. The compact and sturdy design ensures reliable operation under varying conditions while maintaining a long service life. Its easy-to-read dial and smooth pointer movement provide clear visibility even in low-light or vibration-prone environments. This gauge is well-suited for industries that demand consistent accuracy and dependable performance in low-pressure differential measurement tasks.

Key Features:

High-precision capsule element ensures accurate low-pressure differential readings.

Designed for clean rooms, filter monitoring, and HVAC applications.

Offers excellent repeatability and stability across a wide temperature range.

Compact and robust design suitable for both panel and surface mounting.

Highly sensitive movement ensures smooth and reliable pointer response.

Available in a range of pressure scales to suit various industrial requirements.

Engineered for long-lasting performance with minimal maintenance.

Compatible with air and non-corrosive gaseous media.
