Diaphragm pressure gaugeStainless steel version (Price & availability on application)

Diaphragm pressure gaugeStainless steel version (Price & availability on application)

Shipping calculated at checkout.

SKU :

press-product67

Calibration needed
Design EN 837-3 Nominal size in mm 100, 160 Accuracy class 1.6 Scale ranges 0 ... 16 mbar to 0 ... 250 mbar (flange Ø 160 mm) 0 ... 400 mbar to 0 ... 25 bar (flange Ø 100 mm) or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: Full scale value Fluctuating: 0.9 x full scale value Overpressure safety 5 x full scale value, however max. 40 bar Permissible temperature Ambient: -20 ... +60 °C Medium: +100 °C maximum Storage: -40 … +70 °C (scale ranges ≤60 mbar: -20 ... +70 °C) Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.8 %/10 K of full scale value Ingress protection IP 54 per EN 60529 / IEC 529 (with liquid filling Model 433.50) IP 65)
View full details
  • Description
Design EN 837-3 Nominal size in mm 100, 160 Accuracy class 1.6 Scale ranges 0 ... 16 mbar to 0 ... 250 mbar (flange Ø 160 mm) 0 ... 400 mbar to 0 ... 25 bar (flange Ø 100 mm) or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: Full scale value Fluctuating: 0.9 x full scale value Overpressure safety 5 x full scale value, however max. 40 bar Permissible temperature Ambient: -20 ... +60 °C Medium: +100 °C maximum Storage: -40 … +70 °C (scale ranges ≤60 mbar: -20 ... +70 °C) Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.8 %/10 K of full scale value Ingress protection IP 54 per EN 60529 / IEC 529 (with liquid filling Model 433.50) IP 65)
