Capsule Pressure GaugesTest Gauge Series, Class (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product28

Calibration needed?
Design EN 837-3 Nominal size in mm 160 Accuracy class 0.6 Scale ranges 0 ... 10 mbar to 0 ... 600 mbar or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: full scale value Fluctuating: 0.9 x full scale value Operating temperature Ambient: -20 ... +60 °C Medium: +60 °C maximum Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.6 %/10 K of full scale value Ingress protection IP 54 per EN 60 529 / lEC 529
View full details
  • Description
  • Download Brochures

Capsule Pressure Gauges are precision instruments used to measure low-pressure ranges. They operate based on the deflection of a metallic capsule when subjected to pressure changes. These gauges are known for their high sensitivity and are commonly used in applications such as HVAC systems, gas pressure monitoring, and laboratory experiments. Their compact design and accuracy make them suitable for environments where space is limited and precise pressure readings are essential.

Key Features:

Measures low-pressure ranges with high sensitivity

Operates based on metallic capsule deflection

Compact design suitable for limited spaces

Ideal for HVAC systems, gas pressure monitoring, and laboratory use

Provides accurate pressure readings in various applications
