Capsule Pressure Gauges, Square and Edgewise Panel,Mounting Series (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product57

Calibration needed?
Design DIN 43 700 Nominal size in mm 72 x 72, 96 x 96, 144 x 144 and 144 x 72 Accuracy class 1.6 Pressure limitation Steady: full scale value Fluctuating: 0.9 x full scale value Operating temperature Ambient: -20 ... +60 °C Medium: +100 °C maximum Temperature effect When temperature of the measuring system deviates from reference temperature (+20 °C): max. ± 0.6 % / 10 K of true scale value
View full details
  • Description
  • Download Brochures

The Capsule Pressure Gauges – Square & Edgewise Panel-Mounting Series are designed to deliver highly accurate low-pressure measurement in a compact, panel-friendly form. They are ideal for HVAC systems, clean rooms, filtration processes, gas lines, and vacuum monitoring where reliable and easy-to-read measurements are essential. With options in both square and edgewise layouts, they integrate seamlessly into standard DIN control panels. Each gauge is built with a sensitive capsule mechanism that responds quickly to small pressure changes, providing a steady pointer movement and clear indication on the dial. These gauges are rugged enough for industrial conditions yet refined for precision laboratory setups, and they are calibration-ready with local service support to keep them operating at peak accuracy.

Key Features:

Available in square and edgewise panel-mounting formats for versatile installation

Sensitive capsule mechanism for low-pressure and vacuum measurement

Clear, easy-to-read dial with steady pointer movement

Designed to handle steady and fluctuating pressures without loss of accuracy

Compact construction suited to tight instrument panels

Wide operating temperature range for diverse environments

Calibration-ready to ensure traceable, reliable readings

Local support available for calibration, maintenance, and replacement parts
