Capsule Pressure Gauges, Square and Edgewise Panel,Mounting (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product26

Calibration needed?
Design DIN 43 700 Nominal size in mm 72 x 72, 96 x 96, 144 x 144 and 144 x 72 Accuracy class 1.6 Pressure limitation Steady: full scale value Fluctuating: 0.9 x full scale value Operating temperature Ambient: -20 ... +60 °C Medium: +100 °C maximum Temperature effect When temperature of the measuring system deviates from reference temperature (+20 °C): max. ± 0.6 % / 10 K of true scale value
View full details
  • Description
  • Download Brochures

Our Capsule Pressure Gauges offer reliable pressure measurement in compact form, with both square and edgewise panel-mount models available. Designed for clean visual output and secure installation, they perform accurately under vibration and moderate industrial conditions. Calibration-ready and backed by local service, they’re perfect for process control panels and instrument cavities that require dependable readings in small footprints.

Key Features:

Capsule design suited to square and edgewise panel mounting

Compact size for tight instrument panels

Clear, low-profile display for fast reading

Stable and dependable under vibration and industrial use

Calibration-ready for accurate performance

Local support for calibration and mounting assistance
