Bourdon tube pressure gaugeUHP, stainless steel, safety pattern (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product53

Calibration needed?
Design EN 837-1 Nominal size in mm 63 Accuracy class 1.6 Scale ranges 0 ... 1 to 0 ... 400 bar (0 ... 15 to 0 ... 6000 psi) or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: 3/4 x full scale value Fluctuating: 2/3 x full scale value Short time: full scale value Operating temperature Ambient: -40 ... +60 °C Medium: +100 °C maximum Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of full scale value Ingress protection IP 54 per EN 60529 / IEC 529
View full details
  • Description
  • Download Brochures

The UHP Stainless Steel Safety Pattern Bourdon Tube Pressure Gauge is built for ultra-high purity applications demanding both safety and performance. Constructed entirely of stainless steel, including safety pattern shell, this gauge is designed to meet strict hygienic or ultra-clean standards. As a mechanical pressure gauge using a Bourdon tube, it delivers stable analog pressure readings. Pricing and availability depend on chosen materials, range, and certifications.

Key Features:

Ultra-high purity stainless steel construction for cleanliness and corrosion resistance

Safety pattern design with blow-out protection

Bourdon tube mechanism for reliable analog pressure indication

Wide selection of pressure ranges, surface finishes, and connection styles

Custom specifications available to meet specialized requirements

Applications:

Pharmaceutical, biotech, or semiconductor processing where purity matters

Clean room or sterile manufacturing environments

Food & beverage production requiring hygienic instrumentation

Chemical processing where corrosive or ultra-pure media are involved
