Bourdon tube pressure gaugeHP, stainless steel (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

press-product52

Calibration needed?
Nominal size 1 ½", 2" Accuracy class NS 1 ½": Grade B per ASME B40.1 NS 2": Grade A per ASME B40.1 Scale ranges 0 ... 1 to 0 ... 700 bar (0 ... 15 to 0 ... 10,000 psi) or all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitation Steady: 3/4 x full scale value Fluctuating: 2/3 x full scale value Short time: Full scale value Permissible temperature Ambient: -40 ... +60 °C Medium: +100 °C maximum Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of full scale value Ingress protection IP 54 per EN 60529 / lEC 529
View full details
  • Description
  • Download Brochures

The Bourdon Tube Pressure Gauge HP Stainless Steel is engineered for precise pressure measurement in industrial applications. Featuring a stainless steel construction, this gauge ensures durability, corrosion resistance, and reliability in harsh operating conditions. Ideal for hydraulic, pneumatic, and process control systems, it delivers consistent pressure readings with excellent repeatability. Its robust design makes it suitable for high-pressure systems where accurate measurement is essential for operational safety and efficiency.

Key Features:

Stainless steel construction for corrosion resistance and durability

Accurate measurement suitable for hydraulic, pneumatic, and process systems

High-pressure capability for demanding industrial applications

Robust Bourdon tube mechanism ensures long-term reliability

Clear, easy-to-read dial for quick monitoring

Suitable for chemical, water treatment, manufacturing, and industrial environments

Maintenance-friendly design with replaceable components
