Bourdon tube pressure gaugeEdgewise panel (Price & availability on application)

Taxes included. Shipping calculated at checkout.

SKU :

SKU:press-product45

Calibration needed? Yes (office will call you to confirm the cost) No

Design DIN 43700 Nominal sizes in mm 144 x 72 144 x 144 96 x 96 72 x 72 Accurancy class Class 1.0: NS 144 x 72, 144 x 144, 96 x 96 Class 1.6: NS 72 x 72, 96 x 96 Scale ranges NS 144 x 72, 144 x 144, 96 x 96: 0 ... 0.6 to 0 ... 1000 bar NS 72 x 72: 0 ... 0.6 to 0 ... 400 bar or all other equivalent vacuum or combined pressure and vacuum ranges Permissible temperature Ambient: -20 ... +60 °C Medium: +60 °C maximum (soft soldered); +100 °C maximum (brazed) Pressure limitation NS 144 x 72, 144 x 144, 96 x 96 Steady: Full scale value Fluctuating: 0.9 x full scale value Short time: 1.3 x full scale value NS 72 x 72 Steady: 3/4 x full scale value Fluctuating: 2/3 x full scale value Short time: Full scale value Temperature effect When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of full scale value Ingress protection IP 42 per EN 60529 / lEC 529

View full details

Description
Download Brochures

This edgewise‑panel‑mount Bourdon tube pressure gauge delivers reliable, mechanical pressure measurement in instrumentation panels and control cabinets. Designed with a Bourdon tube sensing element, it converts fluid pressure into mechanical motion, providing an analog dial readout. The edgewise mounting allows for flush panel installation, maintaining a clean and professional front‑panel appearance while securely mounting via side or edge connections. With custom configuration options for pressure range, materials and dial size, this gauge can be tailored to your specific process requirements. Pricing and lead times are provided on application basis to match the configuration selected.
